3Com VCX v7111 User Manual page 134

Endpoint Phone Number Table Screen
Figure 45
Configure the nndpoint phone numbers according to
2
in the Phone Number fields for each port that you want to use.
Click Submit to save your changes, or click Register or Un-Register to save your
3
changes and to register or unregister to a Proxy / Registrar.
To save the changes so they are available after a power fail, see
4
Endpoint Phone Number Table
Table 39
Parameter
Channel(s)
Phone Number
134
Description
The numbers (1-8) in the Channel(s) fields represent the ports on the back of
the VoIP gateway.
To enable a VoIP gateway channel, you must enter the port number on this
screen.
[n-m] represents a range of ports. For example, enter [1-4] to specify the ports
from 1 to 4.
In each of the Phone Number fields, enter the telephone number that is
assigned to that channel.
For a range of channels enter the first number in an ordered sequence.
These numbers are also used for port allocation for IP to Tel calls, if the hunt
groups Channel Select Mode is set to By Phone Number.
Table 39. You must enter a number
Saving
®
3Com VCX V7111 VoIP Gateway User Guide
Configuration.
