Parameter
Subnet Mask
Default Gateway Address
OAM Network Settings (available only in Multiple IPs mode)
IP Address
[LocalOAMIPAddress]
Subnet Mask
[LocalOAMSubnetMask]
Default Gateway Address
[LocalOAMDefaultGW]
Control Network Settings (available only in Multiple IPs mode)
IP Address
[LocalControlIPAddress]
Subnet Mask
[LocalControlSubnetMask]
Default Gateway Address
[LocalControlDefaultGW]
Media Network Settings (available only in Multiple IPs mode)
IP Address
[LocalMediaIPAddress]
Subnet Mask
[LocalMediaSubnetMask]
Default Gateway Address
[LocalMediaDefaultGW]
DNS Settings
®
3Com VCX V7111 VoIP Gateway User Guide
Description
Subnet mask of the gateway.
Enter the subnet mask in dotted format notation, for example 255.255.0.0
A warning message is displayed (after pressing the button Submit) if
the entered value is incorrect.
After changing the subnet mask and pressing the button Submit, a
prompt appears indicating that for the change to take effect, the
gateway is to be reset.
IP address of the default gateway used by the gateway.
Enter the IP address in dotted format notation, for example 10.8.0.1.
A warning message is displayed (after pressing the button Submit) if
the entered value is incorrect.
After changing the default gateway IP address and pressing the
button Submit, a prompt appears indicating that for the change to
take effect, the gateway is to be reset.
For detailed information on multiple routers support, see
Support.
The gateways source IP address in the OAM network.
The default value is 0.0.0.0.
The gateways subnet mask in the OAM network.
The default subnet mask is 0.0.0.0.
N/A.
Use the IP Routing table instead (Advanced Configuration > Network
Settings).
The gateways source IP address in the Control network.
The default value is 0.0.0.0.
The gateways subnet mask in the Control network.
The default subnet mask is 0.0.0.0.
N/A.
Use the IP Routing table instead (Advanced Configuration > Network
Settings).
The gateways source IP address in the Media network.
The default value is 0.0.0.0.
The gateways subnet mask in the Media network.
The default subnet mask is 0.0.0.0.
The gateways default gateway IP address in the Media network.
The default value is 0.0.0.0.
Multiple Routers
