If you clear a checkbox and click Submit, all settings in the same row revert to their defaults.
SNMP Managers Table Parameters
Table 66
Parameter
Checkbox
[SNMPManagerIsUsed_x]
IP Address
[SNMPManagerTablexIP_x]
Trap Port
[SNMPManagerTrapPort_x]
Trap Enable
[SNMPManagerTrapSendingEnable_x]
Configuring the SNMP Community Strings
Use the SNMP Community Strings table to configure up to five read-only and up to five read
/ write SNMP community strings, and to configure the community string that is used for
sending traps. For detailed information on SNMP community strings, see
Names.
To configure the SNMP Community Strings:
Access the Management Settings screen (Advanced Configuration menu > Management
1
Settings); the Management Settings screen is displayed
Open the SNMP Community Strings screen by clicking the arrow sign (-->) to the right of
2
the SNMP Community Strings label; the SNMP Community Strings screen is displayed (
Figure
74).
Configure the SNMP Community Strings parameters according to
3
Click the Submit button to save your changes.
4
To save the changes so they are available after a power fail, see
5
202
Description
Up to five parameters, each determines the validity of the
parameters (IP address and port number) of the corresponding
SNMP Manager used to receive SNMP traps.
Checkbox cleared [0] = Disabled (default)
Checkbox selected [1] = Enabled
Up to five IP addresses of remote hosts that are used as SNMP
Managers. The device sends SNMP traps to these IP addresses.
Enter the IP address in dotted format notation, for example
108.10.1.255.
Up to five parameters used to define the Port numbers of the
remote SNMP Managers. The device sends SNMP traps to these
ports.
The first entry (out of the five) replaces the obsolete
parameter SNMPTrapPort.
The default SNMP trap port is 162
The valid SNMP trap port range is 100 to 4000.
Up to five parameters, each determines the activation/deactivation
of sending traps to the corresponding SNMP Manager.
Disable [0] = Sending is disabled
Enable [1] = Sending is enabled (default)
®
3Com
VCX V7111 VoIP Gateway User Guide
SNMP Community
(Figure 72
).
Table
67.
Saving
Configuration.
