Call Counters
The Call Counters screens provide you with statistic information on incoming (IP Tel) and
outgoing (Tel IP) calls. The statistic information is updated according to the release reason
that is received after a call is terminated (during the same time as the end-of-call CDR
message is sent). The release reason can be viewed in the Termination Reason field in the
CDR message. For detailed information on each counter, see
You can reset this information by clicking Reset Counters.
To view the IP Tel and Tel IP Call Counters information:
Open the Call Counters screen you want to view (Status & Diagnostics menu > Gateway
Statistics submenu); the relevant Call Counters screen is displayed.
Tel IP Call Counters Screen
Figure 77
®
3Com VCX V7111 VoIP Gateway User Guide
Table 73 .
