Replacing the Background Image File

The background image file is duplicated across the width of the screen. The number of times
the image is duplicated depends on the width of the background image and screen
resolution. When choosing your background image, keep this in mind.
Use a gif, jpg or jpeg file for the background image. It is important that the image file
has a fixed height of 59 pixels. The size of the image files (logo and background) is
limited each to 64 kbytes.
To replace the background image using the Web:
Access the V7111 Embedded Web Server (see
1
In the URL field, append the suffix AdminPage (note that its case-sensitive) to the IP
2
address, for example, http://10.1.229.17/AdminPage.
Click the Image Load to Device, the Image load screen is displayed (shown in
3
116).
Click the Browse button in the Send Background Image File from your computer to
4
gateway box. Navigate to the folder that contains the background image file you want to
load.
Click the Send File button; the file is sent to the device. When loading is complete, the
5
screen is automatically refreshed and the new background image is displayed.
To save the image to flash memory so it is available after a power fail, see
6
Configuration.
The new background appears on all Web Interface screens.
If you encounter any problem during the loading of the files, or you want to restore
the default images, click the Restore Default Images button.
When replacing both the background image and the logo image, first load the logo
image followed by the background image.
To replace the background image using the ini file:
Place your background image file in the same folder as where the devices ini file is
1
located (that is, the same location defined in the BootP/TFTP configuration utility). For
detailed information on the BootP/TFTP, see
Utility.
Add/modify the ini file parameters in
2
Modifying an ini File.
Note that loading the devices ini file using the Configuration File screen in the Web Interface
does not load the logo image file as well.
312
Accessing the Embedded Web
Appendix C: BootP/TFTP Configuration
Table 90 according to the procedure described in
®
3Com VCX V7111 VoIP Gateway User Guide
Server).
Figure
Saving
