Label Type
Ethernet Link
LAN
Status
Control Control Link
Data Packet Status
Telephone
Channels
Interface

V7111 24 PORT Rear Panel

Figure 5 illustrates the rear panel of the V7111 24 PORT. For descriptions of the V7111 24
PORT rear panel components, see
LEDs, see Table 8.
V7111 24 PORT (FXS) Rear Panel Connectors
Figure 5
28
Color State
Red On
Green On
Red On
Green Blinking
Blank
Green Blinking
Red Blinking
Blank
Green On
Green Blinking
Red On
Blank
Table 7. For the functionality of rear panel Ethernet
3Com
Function
Malfunction
Valid 10/100 Base-TX Ethernet connection
Malfunction
Sending and receiving SIP messages
No traffic
Transmitting RTP (Real-Time Transport
Protocol) Packets
Receiving RTP Packets
No traffic
Offhook / Ringing for FXS Phone Port
FXO Line-Seize/Ringing State for Line Port
There is an incoming call, before answering
Line Malfunction
Normal
®
