Processor Components - Oracle Exadata X10M Service Manual

Table E-5 (Cont.) Drive Components
Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS/MB/SSDR[0-1]/ FRU
SSD[0-1]
Discrete
/SYS/MB/SSDR[0-1]/
SSD[0-1]/PRSNT sensor
/SYS/MB/SSDR[0-1]/ State
SSD[0-1]/STATE sensor
/SYS/MB/SSDR[0-1]/ FRU
SSD[0-1]/NVME
/SYS/MB/SSDR[0-1]/ Discrete
SSD[0-1]/NVME/ sensor
PRSNT

Processor Components

The following table lists the processor (CPU) components.
Table E-6

Processor Components

Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS/MB/P[0- x ] FRU
/SYS/MB/P[0-1 ]/ Discrete
PRSNT sensor
/SYS/MB/P[0- x ]/ Indicator
SERVICE
Memory Device Components
The following table lists the memory device components.
Table E-7 Memory Device Components
Component Name IPMI Type
(Oracle ILOM CLI
Targets)
FRU
/SYS/MB/P[0- x ]/
D[0-11]
Description
Internal SSD drive FRU
SSD drive presence (1 SSD per riser on
2U) (Hidden)
SSD drive state
Internal SSD that is NVM Express FRU
Indicates the SSD is PCIe (NVMExpress)
Description
Host CPU FRU
Host CPU is present.
Host CPU Fault-Service Required LED
Description
Host CPU DIMM FRU
Appendix E
Processor Components
Values (if applicable)
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
04h-INSTALLED
20h-SLOT POWER OFF
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Values (if applicable)
01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
Color: Amber
Location: Motherboard
Off: Normal
On: Processor was diagnosed
as faulty.
Values (if applicable)
E-6
