Adding a Wall Reveal

1 Go to a 3D or non-parallel elevation view.
2 Click Home tab
3 Click Place Reveal tab
4 Select the orientation of the wall reveal: Horizontal or Vertical.
5 Place the cursor over the wall to highlight the wall reveal location. Click to place the reveal.
6 Add the reveal to adjacent walls if needed.
7 To finish placing wall reveals, click in the view away from the wall.
Related topics
Changing the Wall Reveal Profile
Moving Wall Reveals Away from or Towards the Wall
Changing the Wall Reveal Type
Wall Reveal Properties
670 | Chapter 13 Architectural Design
Build panel
Element panel, and select the desired wall reveal from the Type Selector
drop-down.
Revit Architecture preselects the reveal location on each adjacent wall.
on page 671
on page 671
Wall drop-down
on page 671
on page 671
Reveal.
