Isolated Foundation Instance Properties - Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual

Name
Description
Assembly Description
Type Mark
Cost
OmniClass Number
OmniClass title

Isolated Foundation Instance Properties

Name
Constraints
Level
Host
Offset
Moves With Grids
Materials and Finishes
Material
Structural
Rebar Cover - Top Face
Rebar Cover - Bottom Face
Rebar Cover - Other Faces
Estimated Reinforcement Volume
Dimensions
Elevation at Bottom
928 | Chapter 14 Structural Modeling
Description
Enter an optional description of the wall foundation.
Describes the assembly based on the assembly code selection. This is a read-only
parameter.
A value that designates the specific foundation. This value must be unique for each
element in a project. Revit Architecture warns you when the number value is already
used but allows you to continue using it. You can see the warning using the Review
Warnings tool. See Reviewing Warning Messages
The pricing of the foundation.
The number from Table 23 of the OmniClass Construction Classification System
that best categorizes the family type.
The name from Table 23 of the OmniClass Construction Classification System that
best categorizes the family type.
Description
The level to which the slab is constrained.
The level to which the host of the isolated slab is constrained.
Specifies the elevation of the top of the isolated foundation relative to its level.
Changes the column constraint to grid.
Specifies the material of the isolated foundation.
Specifies the distance of the rebar cover from the element top face.
Specifies the distance of the rebar cover from the element bottom face.
Specifies the distance of the rebar cover from the element to adjacent element
faces.
Specifies the estimated reinforcement volume of the selected element. This is a
read-only parameter that only displays when rebar has been placed.
Indicates the elevation used for tagging the Bottom of Foundation.
on page 1415.
