Revealing and Unhiding Hidden Elements

1 On the View Control Bar, click
The Reveal Hidden Elements icon displays with a color border to indicate that you are in Reveal
Hidden Element mode. All hidden elements display in color, and visible elements display in
half-tone.
To unhide hidden elements:
2 Select the element.
3 Do one of the following:
Click Modify <Element> tab
Category.
Right-click the element, and click Unhide in View
NOTE The Unhide Element and Unhide Category options become active when you select an element
that was hidden by element or, a category that was hidden by category.
4 On the View Control Bar, click

Temporarily Hiding or Isolating Elements or Element Categories

Temporarily hiding or isolating elements or element categories may be useful when you want to see or edit
only a few elements of a certain category in a view. The Hide tool hides the selected elements in the view,
and the Isolate tool shows the selected elements and hides all other elements in the view. The tool affects
only the active view in the drawing area.
Element visibility reverts back to its original state when you close the project, unless you make the changes
permanent. Temporary Hide/Isolate also does not affect printing.
To temporarily hide or isolate elements or element categories:
1 In the drawing area, select one or more elements.
.
Reveal Hidden Elements panel
Elements or Category.
to exit Reveal Hidden Elements mode.
Unhide Element or Unhide
Hiding Elements in a View | 209
