Permanent Dimension Instance Properties

Name
Baseline Offset
Equality Display (when a dimension
has an equality constraint) or Value

Spot Elevation Type Properties

Name
Constraints
Rotate with Component
Graphics
Leader Arrowhead
Leader Line Weight
Leader Arrowhead Line Weight
Color
Symbol
Text
Width Factor
Underline
Italic
Bold
Text Size
Text Offset from Leader
Description
Specify an offset value for successive baseline dimensions. This parameter is available
when the Dimension String Type type parameter is set to Baseline.
All linear and angular continuous dimensions have an Equality Display property. It
is set to = by default if there is an equality constraint and to Value by default other-
wise. For more information about this property see
Dimension Value on page 301.
NOTE This property is not available when the Dimension String Type type parameter
is Baseline or Ordinate.
Description
When selected, the spot elevation rotates with the component.
Sets the appearance of the leader arrowhead. The value None removes the arrow-
head. See Specifying Arrowhead Styles
Sets the weight of the leader line. The higher the value, the thicker the line.
Sets the arrowhead line weight. The higher the value, the thicker the arrowhead
line.
Click the button to open the color picker. Sets the color of the spot elevation.
Changes the look of the symbol head with the spot elevation.
Specify a ratio to define the elongation of the text string. A value of 1.0 has no
elongation.
Underlines the spot elevation value and text.
Applies italic formatting to the spot elevation value and text.
Applies bold formatting to the spot elevation value and text.
Sets the size of the elevation text.
Offsets the text from the leader line.
Changing the EQ Label to the
on page 500.
Dimension Properties | 293
