Annotation Location: At the center of the tabbed page is an image of a beam surrounded by six text fields.
The fields represent the locations of the tags as they appear around the beam. The
Select Annotation Type dialog which defines and edits the tag.
None: Tags do not track any particular point on the beam. Changes to the length of the beam do not cause
the tag to move.
Structural Framing Tag: See
Spot Elevation: See Spot Elevations
Structural Framing Tags
This selection enables a pull down menu of available structural family tags specific to the selected location
along the beam. Specific family parameters determine which tags display. Qualifying framing tags must have
the following parameters (see
Rotate with Component is selected.
The Attachment Point parameter is set to <None> or matches the position of the desired tag location in
the Beam Annotations tool.
For example, structural framing tags which have defined Attachment Point parameters of End are only
available to the beam location settings marked <End> in this tool.
Structural Framing Tags on page 855.
on page 856.
Structural Framing Tag Families
buttons open the
on page 853) to be a viable annotations type:
Beam Tags | 855
