Name
Assembly Description
Assembly Code
Type Mark
Cost
Wall Sweep Instance Properties
Name
Constraints
Offset From Wall
Level
Offset From Level
Dimensions
Length
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished

Wall Reveals

A wall reveal is a decorative cutout in a wall. You can add a reveal to a wall from a 3D or elevation view.
Reveals can be horizontal or vertical.
Description
Description of the assembly based on the assembly code selection.
Uniformat assembly code selected from a hierarchical list.
A value to designate the particular wall sweep. This value must be unique for each
wall sweep in a project. Revit Architecture warns you if the number is already used
but allows you to continue using it. You can see the warning using the Review
Warnings tool. See Reviewing Warning Messages
Cost of the materials for constructing the wall sweep. This information can be in-
cluded in a schedule.
Description
The distance from the wall face.
The level of the wall sweep. This property only appears for horizontal wall sweeps.
The wall sweep's offset from the level. This property only appears for horizontal wall
sweeps.
The length of the wall sweep. This is a read-only parameter.
Enter comments for the wall sweep.
A value to designate the particular wall sweep. This value must be unique for each
wall sweep in a project. Revit Architecture warns you if the number is already used
but allows you to continue using it. You can see the warning using the Review
Warnings tool. See Reviewing Warning Messages
The phase when the wall sweep was created.
The phase when the wall sweep was demolished.
on page 1415.
on page 1415.
Wall Reveals | 669
