Name
Phasing
Phase Created
Phase Demolished
Structural Analysis
Start Release
Start Fx
Start Fy
Start Fz
Start Mx
Start My
Start Mz
End Release
End Fx
End Fy
End Fz
End Mx
End My
End Mz
Analyze as
Analytical Model
Vertical Projection
Auto-detect Horizontal Projection
862 | Chapter 14 Structural Modeling
Description
warning using the Review Warnings tool. See
on page 1415.
Indicates in which phase the beam component was created. See
Phasing on page 1331.
Indicates in which phase the beam component was demolished. See
Phasing on page 1331.
Start release conditions. Either Fixed, Pinned, Bending Moment, or User
Defined. User Defined allows you to enable/disable each of the start release
conditions.
Translational release at the start end of the beam along the x-axis.
Translational release at the start end of the beam along the y-axis.
Translational release at the start end of the beam along the z-axis.
Rotational release at the start end of the beam along the x-axis.
Rotational release at the start end of the beam along the y-axis.
Rotational release at the start end of the beam along the z-axis.
End release conditions. Either Fixed, Pinned, Bending Moment, or User
Defined. User Defined allows you to enable/disable each of the end release
conditions.
Translational release at the end of the beam along the x-axis.
Translational release at the end of the beam along the y-axis.
Translational release at the end of the beam along the z-axis.
Rotational release at the end of the beam along the x-axis.
Rotational release at the end of the beam along the y-axis.
Rotational release at the end of the beam along the z-axis.
Used by external analysis applications to determine whether beam conditions
contribute to lateral analysis.
Extends the beam analytical model to the level specified, in the Z direction.
Specifies the placement of the analytical model in the center of the beam.
Reviewing Warning Messages
Project
Project
