Elevation Tag Properties

You can set the following parameters for elevation tags.
Name
Shape
Text Position
Arrow Angle
Filled
Show View Name
View Name Position
Reference Label Position
Line Weight
Color
Line Pattern
Text Font
Text Size
Width

Section Tag Properties

You can set the following parameters for section tags.
Name
Section Head
Section Tail
Broken Section Display Style

View Range

Every plan and RCP view has a view property called View Range, also known as a visible range. The view
range is a set of horizontal planes that control object visibility and display in the view. The horizontal planes
are Top, Cut Plane, and Bottom. The top and bottom clip planes represent the topmost and bottommost
portion of the view range. The cut plane is a plane that determines at what height certain elements in the
view are shown cut. These 3 planes define the primary range of the view range.
Description
Specifies the shape of the elevation symbol.
Specifies the text position for the elevation view.
Sets the thickness of the arrowhead.
Specifies whether the arrowhead is filled in.
Shows the elevation name with the arrowhead.
Aligns the view name with the elevation view arrowhead.
Aligns the reference label with the elevation view arrowhead.
Sets the line weight of the elevation symbol. You can change the definition of the
line weight value using the Line Weights
Sets the color of the symbol.
Sets a line pattern for the elevation symbol. You can use a preset line pattern or
define your own. See Line Patterns
Specifies the typeface for the elevation symbol.
Specifies the size of the text with respect to the scale of the drawing.
Specifies the width of the interior elevation symbol.
Description
Specifies the shape of the section head.
Specifies the shape of the section tail.
Specifies the line pattern of a segmented section. For more information, see
ted Section View on page 140.
on page 495 tool.
on page 496 for more information.
