Room Properties

As model elements, rooms have instance properties. You can change the values of some parameters. Other
parameters are read-only values.
Related topic
Room Tag Properties

Modifying Room Properties

1 In a plan view or section view, select a room and click Modify Rooms tab
2 In the Instance Properties dialog, edit room instance parameters.
3 Click OK.
If you have created a room schedule that includes parameters that can be modified, you can change the
parameter values in the schedule.

Room Instance Properties

Name
Constraints
Level
Upper Limit
Limit Offset
Base Offset
Dimensions
on page 988
panel Element Properties.
See Selecting a Room on page 978.
See Room Instance Properties
Description
The base level on which the room resides. A read-only value. See
Boundary of a Room
The level from which to measure the upper boundary of the room. See
Upper Boundary of a Room
The distance at which the upper boundary of the room occurs, measuring from the
Upper Limit level. Enter a positive number to go above the Upper Limit level, or
enter a negative number to go below it. Enter 0 (zero) to use the level specified for
the Upper Limit. The default is 10' (4000 mm). See
of a Room
The distance at which the lower boundary of the room occurs, measuring from the
base level (defined by the Level parameter). Enter a positive number to go above
the base level, or enter a negative number to go below it. Enter 0 (zero) to use the
base level. The default is 0. See
994.
on page 1003.
on page 994.
on page 993.
on page 993.
Defining the Lower Boundary of a Room
Element
Defining the Lower
Defining the
Defining the Upper Boundary
on page
Room Properties | 1003
