Deleting Members from an Array

You can delete one or more members of an array. If the array was grouped, deleting a member of the array
effectively ungroups the remaining members. Each member of the array then becomes an individual element.
To delete a member element of an array:
1 Select the element to delete from the array.
2 Use any of the following methods to delete the selected element:

Changing an Array

You can modify any dimension associated with array members. If the modified array member is part of a
group, the change affects that element and proportionally affects other members of the group, depending
on the dimension modified. If the modified array member is not part of a group, the change affects the
selected element only. See
If array members belong to a group, you can change the number of members in the array. Select the pattern
line and enter a new value in the array instance number box. Controls for array groups are visible in all
views in which the array is visible. When you modify the number of elements in an array, you can specify
how elements are added to or removed from the array with the Append to End option.
Changing the dimensions of an array
370 | Chapter 8 Editing Elements
Press DEL.
Click Modify <Element> tab
Right-click the element, and click Delete.
Changing a Dimension Value
Modify panel Delete.
on page 286.
