Canceling an Action or Clearing Temporary Dimensions
Key
ESC
ESC
ESC
Views
Key
F8
TAB
Controlling Element Placement
Key
Press and hold
SHIFT
Press and hold
SHIFT
Screen Refresh
Key
F5

Colors

You set colors for many elements in Revit Architecture, such as objects, lines, annotation symbols, materials,
rooms, and phasing. When you select colors, the standard Windows color dialog opens. If you click PANTONE
from the Windows color picker, the PANTONE color dialog opens.
You can specify No Color in the Windows Color dialog to not associate a color with a particular item. This
does not mean the item has no color. A component can assume its color from a parent category or use black.
For example, if you specify No Color for Door Panel, but Doors are defined as brown, the Door Panel displays
in brown.

Using the Windows Color Dialog

1 From the appropriate Revit Architecture dialog, access the Windows Color dialog.
Action
Cancel an action before a first click and return to modify mode
Cancel the first click of a multi-click placement, such as walls or lines. Press ESC again to return to
modify mode.
Clear temporary dimensions that display after a single-click placement, such as doors, or after the
second click of a multi-click placement, such as walls. Press ESC again to return to modify mode.
Action
Activate the SteeringWheel navigation tool.
Create different interior elevation views as you place the Interior Elevation symbol
Action
Constrain the elevation of a window in a 3D view.
Impose or relax the constraint on the movement of a wall or line.
Action
Refresh the screen
For example, in the Materials dialog, on the Graphics tab or the Render Appearance tab, click
a color swatch. (See Materials on page 468.)
Colors | 525
