Name
Distance
Justification
Grid Rotation
V Grid
Layout
Number
Distance
Justification
Grid Rotation
Pattern Application
Indent 1
Indent 2
Component Rotation
Component Mirror
Component Flip
Identity Data
586 | Chapter 11 Conceptual Design Environment
Description
The fixed distance of divisions of the U
grid. See Adjusting UV Grids with the Face
Manager on page 571.
The position from which the U grid is
measured: Beginning, Center, or End. See
Adjusting UV Grids with the Face Manager
on page 571.
The rotation of the U grid. See
UV Grids with the Face Manager
571.
The spacing units of the V grid: Fixed
Number or Fixed Distance. See
UV Grids with the Face Manager
571.
The fixed number of divisions of the V grid.
See Adjusting UV Grids with the Face
Manager on page 571.
The fixed distance of divisions of the V grid.
See Adjusting UV Grids with the Face
Manager on page 571.
The position from which the V grid is
measured: Beginning, Center, or End. See
Adjusting UV Grids with the Face Manager
on page 571.
The rotation of the V grid. See
UV Grids with the Face Manager
571.
The number of U grid divisions by which
the pattern is shifted when applied.
The number of V grid divisions by which
the pattern is shifted when applied.
The rotation of a pattern component family
in its pattern cell: 0°, 90°, 180°, or 270°.
Mirrors the component horizontally along
the U grid.
Flips the component along the W grid.
Adjusting
on page
Adjusting
on page
Adjusting
on page
