Wall Sweeps

A wall sweep is a horizontal or vertical projection from a wall, often decorative in nature. Examples of wall
sweeps include baseboards along the bottom of a wall or crown molding along the top of a wall. You can
add a wall sweep to a wall from a 3D or elevation view.
You can schedule wall sweeps. Integral wall sweeps, which are part of the wall type definition, can not be
scheduled independently. For more information on creating schedules, see
NOTE If you create wall sweeps at different heights and then later set them to the same height, the sweeps miter
at the joins.

Adding Wall Sweeps

1 Go to a 3D or elevation view.
2 Click Home tab
3 Click Place Wall Sweep tab
4 Select the orientation of the wall sweep: Horizontal or Vertical.
5 Place the cursor over the wall to highlight the wall sweep location. Click to place the wall sweep.
6 Add the wall sweep to adjacent walls, if needed.
7 To start a wall sweep in a different location, click Place Wall Sweep tab
8 To finish placing wall sweeps, click Modify.
664 | Chapter 13 Architectural Design
Build panel
Type Selector drop-down.
Revit Architecture preselects the wall sweep location on each adjacent wall.
If you are in a 3D view, you can add a wall sweep to all exterior walls by using the ViewCube
to rotate the view. For more information, see
Current. Move the cursor to the desired location on the wall, and click to place the wall sweep.
Wall drop-down Wall Sweep.
Element panel, and select the desired type of wall sweep from the
ViewCube
Schedule Views on page 172.
on page 217.
Profile panel Finish
