Related topics
Revisions
Revision Clouds
Revision Workflow

Assigning a Revision to a Revision Cloud

When you add a revision cloud to a view, by default Revit Architecture assigns the most recent revision to
the cloud. If needed, you can assign a different revision to the cloud. You can assign one revision to each
cloud, or assign the same revision to multiple clouds.
To assign a revision to a cloud
1 In a project view, select the revision cloud.
2 On the Options Bar, for Revision, select the desired revision from the list.
As an alternative, you can right-click a revision cloud, and click Element Properties. On the Instance Properties
dialog, for Revision, select the desired revision from the list.

Modifying a Revision Cloud

You can change the boundaries of a revision cloud. You can also change the line weight, color, and style of
one cloud or of all clouds in the project.
To change the boundaries and appearance of a revision cloud
1 In a project view, select the revision cloud.
2 To change its boundaries, do the following:
3 To change the appearance of the cloud, do the following:
To change the appearance of all revision clouds
1 In the project, click Manage tab
2 Click the Annotation Objects tab.
3 For Revision Clouds, change the values for Line Weight, Line Color, and Line Pattern.
4 Click OK.
1076 | Chapter 17 Preparing Construction Documents
on page 1069
on page 1075
on page 1070
If you have not yet entered information for the revision that you want to assign to the cloud,
see Entering Revision Information
a Click Modify Revision Clouds tab
Revit Architecture enters sketch mode.
b Select segments of the revision cloud, and drag the endpoints to adjust its boundaries.
c Click Modify Revision Clouds > Edit Sketch tab
a Right-click the cloud, and click Override Graphics in View
b Change the values for the Weight, Color, and Pattern of the cloud lines.
c Click OK.
These changes apply to all revision clouds in the project.
on page 1070.
Edit panel Edit Sketch.
Revision Cloud panel
Project Settings panel
Finish Cloud.
By Element.
Settings drop-down Object Styles.
