clouds. However, you can force the sheet to list the revisions, if desired. See
Include in a Revision Schedule
Crop region. If all or part of a revision cloud is outside the model crop region of a view, the cloud does
not display in the view. See
Hide in view > Elements. In a view, select one or more revision clouds, right-click, and click Hide in
view

Revision Cloud Properties

The following table describes parameters for revision clouds. To see or change these parameters, right-click
a revision cloud in a view, and click Element Properties.
Name
Revision
Revision Number
Revision Date
Issued to
Issued by
Mark
Comments

Revision Schedules on Sheets

Most title blocks for sheets include a revision schedule. When you place a view on a sheet and the view
includes revision clouds, the revision schedule automatically displays information about those revisions. If
desired, you can specify that other revisions (not represented by revision clouds in the view) are to display
in the revision schedule,
To display a revision schedule on a sheet, use a title block that includes a revision schedule. When designing
the revision schedule, you can specify its format, orientation on the page, information that it displays, and
sort order. You control these attributes of the revision schedule by modifying the title block family. See
Revision Schedules on Title Blocks
1078 | Chapter 17 Preparing Construction Documents
on page 1079.
Crop Regions
Elements.
Description
The revision assigned to the cloud. To change the assigned revision, select a revision from the
list. (See Entering Revision Information
on page 1076.)
A number assigned to the cloud, which displays in a revision tag and a revision schedule on a
sheet. Its value depends on the assigned revision and the cloud numbering method. (See
Cloud Numbering by Project or by Sheet
The date of the assigned revision, based on the Date column of the Sheet Issues/Revisions dialog.
This value is read-only.
For the assigned revision, the value of the Issued to column of the Sheet Issues/Revisions dialog.
This value is read-only.
For the assigned revision, the value of the Issued by column of the Sheet Issues/Revisions dialog.
This value is read-only.
A unique identifier for the revision cloud.
A text field that you can use to store information about the revision cloud.
on page 1049.
on page 211.
on page 1070 and
on page 1072.) This value is read -only.
Specifying the Revisions to
Assigning a Revision to a Revision Cloud
Revision
