5 Add views to the sheet.
6 Change the default number and name that Revit Architecture assigned to the sheet.
NOTE To track printing times, Revit Architecture displays a date and time stamp on sheets. To format the display
of this stamp, modify the regional and language settings on your computer.
Related topics
Sheets Overview
Creating a Title Sheet
Sheet Properties

Adding Views to a Sheet

You can add one or more views of a building to a sheet, including floor plans, site plans, ceiling plans,
elevations, 3D views, sections, detail views, drafting views, and rendered views. Each view can be placed on
one sheet only. To add a particular view to multiple sheets in a project, create duplicate views, and place
each one on a different sheet.
NOTE You can also place legends and schedules (including view lists and drawing lists) on sheets. Legends and
schedules can be placed on multiple sheets. See
To add views to a sheet
1 Open the sheet.
2 To add a view to the sheet, use one of the following methods:
3 As you move the cursor over the sheet in the drawing area, a viewport for the selected view
4 Repeat Steps 2 and 3 to add more views to the sheet, if desired.
5 If needed, you can modify the individual views on the sheet as follows:
See Adding Views to a Sheet
See Renaming a Sheet on page 1037. The sheet number and name display in the Project Browser
under Sheets (all).
on page 1030
on page 1040
on page 1044
In the Project Browser, expand the list of views, locate the view, and drag it onto the sheet.
Click View tab Sheet Composition panel
click Add View to Sheet.
moves with it. Click to place the viewport in the desired location.
To change the view title that displays on the sheet, double-click the title, and edit it. See
View Titles on Sheets
To move the view to a new location on the sheet, select its viewport, and drag it.
on page 1033.
Adding a Schedule to a Sheet
on page 1059.
on page 1063.
View. In the Views dialog, select a view, and
