3 In the value box of the Structure property, click Edit.
4 In the Edit Assembly dialog, specify the material for layers and the thickness of those layers. The variable
thickness parameter column will contain empty check boxes next to layers where variable thickness
can be enabled. For more information about the Edit Assembly dialog, see
page 813.
5 Next to the desired layer of the roof or structural floor in the assembly, select the variable check box
6 Click OK until all of the dialogs are closed.
7 Click Modify Floors tab
to your roof or structural floor. For more information, see
946.

Structural Component Tags

Structural components can be annotated with tag components as needed. Some structural component
instances are annotated by default when they are placed. For example, beam size is displayed when you add
a beam to your model.
Structural framing tag families are available in the Annotations folder of the Library folder. You have a choice
of loading a several different tags, depending upon the component. For information about loading a family,
see Loading Families
Columns and structural floors are not annotated by default in plan view. You can place their tags by using
the Tag button. For example, to tag a column, click Annotate tab
in the plan view. The column size tag will be placed in your view. For more information about tags, see
on page 1123.
Shape Editing panel
on page 427.
Modify Sub Elements and make the desired changes
Using the Modify Sub Elements Tool
Tag panel
Structural Component Tags | 951
Compound Structure on
on page
Tag, and select a column
Tags
