Issuing a Revision

After you have completed revisions to a project and added the revised views to a sheet, you can issue the
revision. In Revit Architecture, marking a revision as Issued means the following:
On the Sheet Issues/Revisions dialog, you can no longer change information for that revision.
In project views, you can no longer assign the issued revision to additional (new) revision clouds.
You cannot edit revision clouds to which the issued revision is assigned.
To issue a revision
1 In the project, click View tab
2 In the Sheet Issues/Revisions dialog, do the following:
3 Print or publish the revised sheets. See

Printing

The Print tool prints the current window, a visible portion of the current window, or selected views and
sheets. You can send the desired drawings to the printer, to a PRN or PLT file, or to a PDF file.
Printed output in Revit Architecture is What You See Is What You Get (WYSIWYG), with a few exceptions:
The background color on the print job is always white.
By default, reference planes, work planes, crop boundaries, unreferenced view tags, and scope boxes do
not print. To include them in the print job, in the Print Setup dialog, clear the corresponding Hide
options.
The print job includes elements that have been hidden from a view using the Temporary Hide/Isolate
tool.
Line weights modified by the Thin Lines tool print at their default line weight.
Related topics
Exporting to CAD Formats
Exporting to Design Web Format
Publishing to Buzzsaw
1080 | Chapter 17 Preparing Construction Documents
a For Issued to, indicate the person or organization to whom the revisions will be issued.
b For Issued by, indicate the person or organization who will issue the revision.
c Check the other values for the revision row (such as Date and Description). Update them
if needed.
d Select Issued.
Most of the revision row displays as read only. After selecting Issued, you cannot make
further changes to the revision information.
NOTE If you must change any revision information after issuing the revision, clear Issued, make
the changes, and then select Issued again.
e Click OK.
on page 1341
on page 1355
on page 1384
Sheet Composition panel
Printing on page 1080 or
(Sheet Issues/Revisions).
Publish on page 1381.
