NOTE When Revit Architecture computes the volume of materials for individual layers within a wall, some
approximations are made to maintain performance. Minor discrepancies might appear between the volumes
visible in the model and those shown in the material takeoff schedule. These discrepancies tend to occur when
you use the wall sweep tool to add a sweep or a reveal to a wall, or under certain join conditions.

Creating a Material Takeoff Schedule

1 Click View tab
2 In the New Material Takeoff dialog, click a category for the material takeoff schedule, and click
3 In the Material Takeoff Properties dialog, for Available Fields, select the material attributes.
4 Optionally, sort and group, or format the schedule. See
5 Click OK to create the material takeoff schedule.
The material takeoff schedule displays, and the view is listed in the Project Browser under Schedules/Quantities.

Annotation Schedules (Note Blocks)

Annotation schedules, or note blocks, list all instances of annotations that you can add using the Symbol
tool. See Creating an Annotation Symbol Family
Note blocks are useful for listing notes that are applied to elements in your project. For example, you might
want to attach a note to several walls, and that note might have a building description for each of the walls.

Creating an Annotation Schedule (Note Block)

1 Load the generic annotation family or families into your project and place them where desired.
2 Click View tab
3 In the New Note Block dialog, for Family, select a generic annotation.
4 For Note Block Name, enter a name for the new note block, if desired.
5 Click OK.
6 In the Note Block Properties dialog, for Available Fields, select the parameters to set, and then
7 Complete any information in the additional Note Block properties tabs. For more information
Create panel
OK.
176.
Be sure to enter meaningful information in the parameter values for the annotation. For example,
enter some comments for the Description parameter.
Create panel
click Add to add them to Scheduled Fields list.
about the tabs, see Specifying Schedule Properties
Schedules drop-down
Specifying Schedule Properties
on page 1132.
Schedules drop-down
on page 176.
Annotation Schedules (Note Blocks) | 175
Material Takeoff.
Note Block.
on page
