Beam Type Properties - Concrete - Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual

Name
Type Comments
URL
Description
Assembly description
Type Mark
Cost
OmniClass Number
OmniClass title

Beam Type Properties - Concrete

Properties will vary depending on the beam families that are specified during the installation process. The
following type properties apply to the concrete beam families that load during a typical installation:
Name
Structural
b
h
Identity Data
Assembly Code
Keynote
Model
Manufacturer
Type Comments
URL
Description
Description
A field for entering general comments about the shape type. This information can
be included in a schedule.
A link to a web page that may contain type-specific information.
Description of the beam. Enter a description.
Description of the assembly based on the assembly code selection. This is a read-
only value.
A value that designates the particular beam; possibly the shop mark. This value must
be unique for each element in a project. Revit Architecture warns you if the number
is already used but allows you to continue using it. You can see the warning using
the Review Warnings tool. See
The pricing of the beam.
The number from Table 23 of the OmniClass Construction Classification System
that best categorizes the family type.
The name from Table 23 of the OmniClass Construction Classification System that
best categorizes the family type.
Description
Beam width.
Beam depth.
Uniformat assembly code selected from a hierarchical list.
The beam keynote. Add or edit the value. Click in the value box to open the Keynotes
dialog. See Keynotes on page 1117.
The manufacturer internal number.
The shape manufacturer.
A field for entering general comments about the shape type. This information can
be included in a schedule.
A link to a web page that may contain type-specific information.
Description of the beam. Enter a description.
Reviewing Warning Messages
Beam Properties | 859
on page 1415.
