2 Click Modify Doors tab
drop-down.

Modifying the Door Position

1 In a plan view, select the door.
2 Right-click to open the shortcut menu.
3 Choose from the following options:
Flip Hand: flips the door horizontally. This option is available only if the particular door
family was created with horizontal controls.
Flip Facing: flips the door vertically. This option is available only if the particular door family
was created with vertical controls.
Also see Rehosting on page 811 for information about moving a door from one host to another.

Door Properties

You can modify several properties for doors, including the sill height, frame material, and thickness.
NOTE This topic contains information on common door properties. However, properties can vary among the
different door types (families).
Modifying Door Properties
1 From a plan view, select the door, and click Modify Doors tab
Properties.
2 In the Instance Properties dialog, edit door instance parameters.
See Door Instance Properties
3 Click Edit Type to edit door type parameters.
See Door Type Properties
NOTE Changes made to type parameters affect all doors of this type in the project. You can click
Duplicate to create a new door type.
4 Click OK.
Door Type Properties
Name
Construction
Wall Closure
Construction Type
Function
Element panel, and select a different door type from the Type Selector
on page 801.
on page 799.
Description
The layer wrapping around the door. It overrides any settings in the host.
The type of construction for the door.
Indicates whether a door is interior (default value) or exterior. Function is used in
scheduling and to create filters to simplify a model when exporting.
Element panel Element
