If you want to...
hide a field in a schedule
TIP You can show or hide any columns while in the schedule view. To hide a column, select a cell in the column,
and then right-click. From the shortcut menu, select Hide Column(s). To display all hidden columns, right-click
in the schedule view, and select Unhide All Columns.
Appearance Tab Options
If you want to...
display grid lines around schedule rows
extend vertical grid lines into headers, footers, and spaces
display a border around the schedule
specify the font for the heading text
display the title of the schedule
display the scheduled fields as column titles
insert a blank row before the data rows
specify the font for the body text
Formatting Units and Number Fields in a Schedule
1 In the Project Browser, right-click the schedule name, and select Properties.
2 In the Instance Properties dialog, for Formatting, click Edit.
3 Select a length (includes height fields), area, volume, angle, or Number field from the list.
184 | Chapter 5 Project Views
then...
select the field, then select Hidden field. This option is useful
when you want to sort the schedule by a field, but you do
not want that field to display in the schedule.
then select...
Grid lines, and then select the grid line style from the list.
Grid in headers/footers/spacers.
Outline, and then select a line style from the list. The border
displays when you add a schedule to a sheet view. If you clear
this option, but the Grid lines option is still selected, the grid
line style is used as the border style.
a font from the list, enter a font size, and select bold or italic
attributes.
Title. To create a different underscore line style, select Under-
line, and then select the line style from the list.
Column headers. To create a different underscore line style,
select Underline, and then select the line style from the list.
Blank row before data. This option affects both the schedule
segment on the sheet and the schedule view.
a font from the list, enter a font size, and select bold or italic
attributes.
