When a level is selected, the following information displays in the drawing area:
the level elevation
the level name
the distances between the selected level and its surrounding levels
the drag handles used to change the level area

Creating 3D Levels

1 Click Create tab Datum panel
2 Move the cursor in the drawing area until the desired elevation displays, and click to place the level.
Continue to place levels, as needed.
3 Click Place Level tab

Changing the Height Between 3D Levels

To change the height between levels, drag it a level the desired height, or explicitly set the height by typing
in a new height value. When you move a middle level, the top and bottom levels remain in place, and the
heights of the other levels adjust between them.
1 Click a 3D level. The level highlights and displays the dimension length value.
2 Click the value.
3 Enter a new dimension in the text box.
The 3D levels adjust so that their dimensions equal the parameter value.

Changing 3D Level Elevations

1 Click a 3D level.
2 Click an elevation value in the drawing area.
3 Enter a new elevation value in the text box.
4 Press Enter.
The new 3D level elevations are set.

Changing 3D Level Names

1 Click a 3D level. The level name displays.
Level.
Selection panel Modify to stop placing levels.
3D Levels | 537
