Name
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished
Analytical Model
Enable Analytical Model
Horizontal Projection
Top Vertical Projection
Bottom Vertical Projection

Wall Foundations

Wall foundations are members of the structural foundation category. You can place these foundations along
structural walls, in either a plan or 3D view.
Wall foundations are constrained to the wall that they support. They move with the wall when you move
the wall.
You join wall foundations using the Join tool.
See also:
Isolated Foundations
Foundation Slabs

Creating a Wall Foundation

Foundations snap to walls.
Description
Indicates the volume of the wall. This is a read-only value.
A field for entering comments about the wall.
A label created for the wall. This value must be unique for each element in a
project. Revit Architecture warns you when the number is already used but allows
you to continue using it. You can see the warning using the Review Warnings
tool. See Reviewing Warning Messages
Indicates in which phase the wall component was created. See
on page 1331.
Indicates in which phase the wall component was demolished. See
Phasing on page 1331.
Changes the visibility of the wall analytical model.
The horizontal plane of the wall used for analysis and design.
The top vertical plane of the wall used for analysis and design.
The bottom vertical plane of the wall used for analysis and design.
on page 925
on page 940
on page 1415.
Project Phasing
Project
Wall Foundations | 915
