2 In the Apply View Template dialog, select a type from the Show type list.
3 In the Names list, select the view template you want to apply.
4 Click Apply.
5 Click OK.
The view template is applied to all views on the sheet.

Deleting a View Template

1 Click View tab
2 In the View Templates dialog, select a type from the Show type list.
3 In the Names list, select the view template you want to delete.
4 Click

View Template Properties

You can access view template properties from View tab
drop-down
Name
View Scale
Scale Value 1:
Display Model
Detail Level
V/G Overrides Model
V/G Overrides Annotation
510 | Chapter 10 Customizing Project Settings
specifying the default view template for a view, see
Template on page 509.
You can use the view properties of another project view as a view template. To do this, select
Show Views and select the view name.
Graphics panel
(Delete).
NOTE Because templates are not linked to views, deleting a view template has no impact on existing
views.
View template settings. Not all properties are available for each view template type.
Description
The scale of the view. When you select Custom, you can edit the Scale Value
property.
A ratio derived from the view scale. For example, if the view scale is 1:100, the
scale value is the ratio of 100/1 or 100. You can edit this value when you select
Custom for the View Scale property.
Hides the model in detail view. The Normal setting displays all elements normally.
It is intended for all non-detail views. The Do Not Display setting shows only detail-
view–specific elements. These elements include lines, regions, dimensions, text,
and symbols. Elements in the model do not display. The As Underlay setting displays
all detail-view–specific elements, while model elements are dimmed. You can use
the underlay model elements as references for tracing lines, dimensioning, and
aligning. (See
Applies the detail level setting to the view. See
Click Edit to view and modify visibility options for model categories. See
and Graphic Display in Project Views
Click Edit to view and modify visibility options for annotation categories. See
ility and Graphic Display in Project Views
Specifying and Applying a Default View
View Templates drop-down
Graphics panel
Halftone/Underlay on page 497.)
on page 198.
on page 198.
View template settings.
View Templates
Detail Level on page 511.
Visibility
Visib-
