Name
Border 1 Type
Border 2 Type
Identity Data
Keynote
Model
Manufacturer
Type Comments
URL
Description
Assembly Description
Assembly Code
Type Mark
Fire Rating
Cost
Curtain Wall Instance Properties
Name
Constraints
Base Constraint
Base Offset
Base is Attached
Top Constraint
Unconnected Height
Top Offset
788 | Chapter 13 Architectural Design
Description
Specifies the mullion family for horizontal mullions on the left border.
Specifies the mullion family for horizontal mullions on the right border.
Add or edit the curtain wall keynote. Click in the value box to open the Keynotes
dialog. See Keynotes on page 1117.
The model type for the curtain wall. May not be applicable.
Manufacturer for the stair materials. May not be applicable.
Specific comments on the curtain wall type.
A link to a web page for the manufacturer or other appropriate link.
A description for the curtain wall.
Description of the assembly based on the assembly code selection.
Uniformat assembly code selected from hierarchical list.
A value to designate the particular curtain wall. Useful if you need to identify
more than one curtain wall. This value must be unique for each curtain wall in
a project. Revit Architecture warns you if the number is already used but allows
you to continue using it. (You can see the warning using the Review Warnings
tool. See Reviewing Warning Messages
The fire rating of the curtain wall.
Material cost.
Description
The base level of the curtain wall. For example, Level 1.
Sets the curtain wall's height from its base constraint. This property is available
only when the Base Constraint is set to a level.
Indicates whether the base of the curtain wall is attached to another model
component, such as a floor. This is a read-only value.
Curtain wall height extends to the value specified in Unconnected Height.
The height of the curtain wall when it is sketched.
Sets the curtain wall's offset from the top level.
on page 1415.)
