Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual page 942

Name
Brace Material
Structural
Angle
Moment Connection Start
Moment Connection End
Cut Length
Structural Usage
Start Attachment Level Reference
Start Attachment Elevation
End Attachment Type
End Attachment Ratio
End of Referenced Element
Dimensions
Length
Volume
Identity Data
Comments
Mark
Phasing
Phase Created
Phase Demolished
900 | Chapter 14 Structural Modeling
Description
Specifies the user-defined structural material. See
on page 489.
The rotation about the longitudinal axis of the brace.
The moment frame, or cantilever symbol at the start end of brace, if applicable.
The moment frame, or cantilever symbol at the finish end of brace, if applicable.
The physical length (not the analytical length). This is a read-only value.
Specifies Vertical Bracing, Kicker brace, or Other.
Distance or Ratio (percentage relative to beam length); type of separation of brace
start end to a designated beam end. Applies to the brace end attached to the beam.
Distance from, or Ratio (percentage) of separation of brace start end to a designated
beam end. Applies to the brace end attached to the beam.
Distance of separation of brace finish end to a designated beam end. Applies to the
brace end attached to the beam.
Ratio (percentage) of separation of brace finish end to a designated beam end. Ap-
plies to the brace end attached to the beam.
Designated end (start or finish) of Referenced Element (beam) to which start end
of brace is attached. Applies to the brace end attached to the beam.
The distance between the component endpoints that define the element's location.
This is a read-only value.
The volume of the selected brace element. This is a read-only value.
A field for entering comments about the brace.
A label created for the brace. Possible use: shop mark. This value must be unique
for each brace in a project. Revit Architecture warns you if the number is already
used but allows you to continue using it. You can see the warning using the Review
Warnings tool. See Reviewing Warning Messages
Indicates in which phase the brace component was created. See
page 1331.
Indicates in which phase the brace component was demolished. See
on page 1331.
Material Physical Type Parameters
on page 1415.
Project Phasing
Project Phasing
on
