Name
Location Line
Base Constraint
Base Offset
Base is Attached
Base Extension Distance
Top Constraint
Unconnected Height
Top Offset
Top is Attached
Top Extension Distance
Room Bounding
Related to Mass
Structural
Rebar Cover - Exterior Face
Rebar Cover - Interior Face
Rebar Cover - Other Face
Estimated Reinforcement Volume
Structural Usage
Dimensions
Length
Area
914 | Chapter 14 Structural Modeling
Description
Specifies the position of the wall with respect to the line sketched in the project
elevation. For more information, see
634. The wall location line remains the same for that wall, even if the type changes.
Specifies the level from which the wall base is referenced.
Specifies the offset of the base of the wall from its base constraint.
Indicates whether the base of the wall is attached to another component, such
as a structural floor. This is a read-only value.
Indicates the distance you have moved the base of the layers in a wall. See
Compound Structure on page 813. This parameter is enabled when the layers of
a wall are set to extendable.
The name of the level to which the wall top is set.
If top constraint is unconnected, you may set an unconnected height of the
wall. This value is read-only if there is a top constraint.
Specifies the offset of the top of the wall from its top constraint; enabled only
when the top constraint is set to a level.
Indicates whether the top of the wall is attached to another component, such
as a structural floor. This is a read-only value.
Indicates the distance you have moved the top of the layers in a wall. See
Compound Structure on page 813. This parameter is enabled when the layers of
a wall are set to extendable.
Indicates whether the wall is part of a room boundary. This parameter is enabled
after you place the wall.
This is a read-only value.
Specifies the rebar cover distance from the wall exterior face.
Specifies the rebar cover distance from the wall interior face.
Specifies the rebar cover distance from the face of adjacent element.
Specifies the estimated reinforcement volume of the selected element. This is a
read-only parameter that only displays when rebar has been placed.
The structural use of the wall.
Indicates the length of the wall. This is a read-only value.
Indicates the area of the wall. This is a read-only value.
Adding Interior and Exterior Walls on page
