Several components are already defined. To create more, define them in the Family Editor. See
Guide on page 418.
For information about moving a component from one host to another, see
To place a component
1 If necessary, load the component family.
2 Click Home tab
3 Click Place Component tab
4 Place the cursor in the drawing area where you want the component to appear.
5 If you are placing a work plane-based or face-based component, select Place on Vertical Face,
6 Press Spacebar to rotate the component through its different snap points to other elements.
7 Click to place the component.

Work Plane-based and Face-based Component Placement Options

Following are the options for placing work plane-based and face-based components:
Place on Vertical Face (only available for some components)
810 | Chapter 13 Architectural Design
For information about loading a family, see
Build panel
drop-down.
Place on Face, or Place on Work Plane from the Placement panel.
See Work Plane-based and Face-based Component Placement Options
of these options.
NOTE After you place a component, you can select it and then select the Moves With Nearby Elements
option. For example, if you place a bed next to a wall and then move the wall, the bed moves with
the wall. Revit Architecture determines which element the component is locked to; you do not have
explicit control. You can move the component independently of the element. See
Components with Walls on page 376.
Loading Families
Component drop-down
Element panel, and select a component from the Type Selector
The Families
Rehosting on page 811.
on page 427.
Place a Component.
on page 810 for descriptions
Moving Lines and
