Use either the Pick Support or Lines tool to sketch an opening in the beam system. For more
information, see
6 Click Create Beam System Boundary tab
Floor plan and 3D view of completed structural beam system.
Sketching a Beam System Boundary
You can use the sketching tools to define the perimeter of a beam system. You can also use these tools to
modify a beam system boundary, created using the Pick Supports method.
1 Click Home tab
2 Click Place Beam System tab
3 Click Create Beam System Boundaries tab
System Boundaries tab
4 Draw or pick the lines that define the beam system boundary.
Cutting an Opening in a Beam System
Build panel Beam drop-down
Sketch panel
Draw panel Pick Line to select existing lines.
on page 881.
Beam System panel Finish Beam System.
Beam System.
Create Sketch.
Draw panel Line to sketch, or click Create Beam
Creating a Structural Beam System | 879
