NOTE To track printing times, Revit Architecture displays a date and time stamp on sheets. To format the display
of this stamp, modify the regional and language settings on your computer.

Modifying Sheet Properties

To modify sheet properties, do either of the following:
In the Project Browser, right-click the sheet name, and click Properties.
Open the sheet. Right-click in the drawing area, and click View Properties.
You can modify the properties of multiple sheets in one operation. For example, you can change the Sheet
Issue Date for several sheets in one step. In the Project Browser, while pressing Ctrl, click to select non-adjacent
sheet names, or while pressing Shift, click to select adjacent sheet names. Then right-click, and click Properties.
When you use this method, changes that you make to the view properties affect all selected sheets.

Sheet Instance Properties

Name Description
Visibility/Graphics Click Edit to display the Visibility/Graphics Overrides dialog for the sheet. See
Overrides Display in Project Views
Scale The scale of the views on the sheet. If the sheet contains multiple views displayed at different scales,
this parameter shows the value As indicated.
Dependency Indicates whether views on the sheet are dependent on other views. See
Views
Referencing Sheet See the description for Referencing Detail, which follows. From the example, the referencing sheet
is A101.
Referencing Detail This value comes from the referencing view that is placed on a sheet. For example, you create a
section in a plan view and place the plan view as the first detail on a sheet numbered A101. The
referencing detail number for the section view is 1. See
and
Current Revision De- If the project has revisions, the description of the most recent revision displayed on the sheet. See
scription Revisions
Current Revision If the project has revisions, the sequence number of the most recent revision displayed on the sheet.
See
Approved By The person who approved the plans.
Designed By The person who designed the plans.
Checked By The person who checked the drawing.
Sheet Number A unique identifier for the sheet in the construction document set.
Sheet Name Brief description of the sheet. This name displays in the Project Browser, drawing lists, and other
areas of Revit Architecture.
on page 198.
on page 192.
Referencing a Callout View on page 1137.
on page 1069.
Revisions on page 1069.
Visibility and Graphic
Duplicate Dependent
Referencing a Drafting View on page 1141
Sheet Properties | 1045
