Matchline Properties; Navigating Primary And Dependent Views - Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual

2 Click Modify Matchline tab
3 Edit the sketch line as necessary.
4 When finished, click Finish Matchline.
To override matchline graphic format in a view:
1 Click View tab
2 Click the Annotation Categories tab.
3 Select Matchline from the list.
4 Click Override in the Lines column.
5 In the Line Graphics dialog, select values for Line Weight, Line Color, and Line Pattern, and
6 Click Apply to see your changes, and click OK to exit the Visibility/Graphics dialog.

Matchline Properties

The following matchline properties are available for matchlines drawn in plan and callout views.
NOTE Matchline properties are not available in elevation or sections views, because specifying top and bottom
level constraints do not apply in these view types.
Name
Constraints
Top Constraint
Top Offset
Bottom Constraint
Bottom Offset

Navigating Primary and Dependent Views

Use any of the following methods to navigate between primary and dependent views.
To go to the primary view from a dependent view, right-click a dependent view crop boundary, and click
Go to Primary View.
To go to a dependent view from the primary view, right-click the crop boundary of the view you want
to go to, and click Go to View.
If there is a view reference, double-click it to open the view that it references. The following image shows
view references (1/A102 and 1/A101) on the matchline.
196 | Chapter 5 Project Views
Graphics panel
click OK.
Description
Specify the top level on which the matchline is visible.
Specify a distance above the top level on which you want the matchline to be visible.
Specify the bottom level on which the matchline is visible.
Specify a distance below the bottom level on which you want the matchline to be visible.
Edit panel Edit Sketch.
Visibility/Graphics, or use the keyboard shortcut VG.
