Name
Tick Mark
Line Weight
Tick Mark Line Weight
Dimension Line Extension
Flipped Dimension Line Extension
Witness Line Control
Witness Line Length
Witness Line Gap to Element
Witness Line Extension
Centerline Symbol
Centerline Pattern
Centerline Tick Mark
Interior Tick Mark
Description
Ordinate places a dimension string with values measured from the dimension
origin.
The name of the tick mark style.
Sets the line weight number that designates thickness of the dimension line. You
can select from a list of values defined in Revit Architecture or define your own. You
can change the definition of the line weights by clicking Manage tab
Settings panel Settings drop-down
495.
Sets the line weight that designates thickness of the tick mark. You can select from
a list of values defined in Revit Architecture or define your own.
Extends the dimension line beyond the intersection of the witness lines to the spe-
cified value. When you set this value, this is the size at which the dimension line
plots, if you are printing at 100 percent.
Controls the extent of the dimension line beyond the flipped arrow if the arrow flips
on the ends of the dimension string. This parameter is only enabled when the tick
mark type parameter is set to an arrow type. See
Mark on page 287.
Switches between the fixed gap functionality and the fixed dimension line function-
ality.
If Witness Line Control is set to Fixed to Dimension Line, this parameter becomes
available. Specifies the length of all witness lines in the dimensions. When you set
this value, this is the size at which the witness line plots, if you are printing at 100
percent.
If Witness Line Control is set to Gap to Element, this parameter sets the distance
between the witness line and element being dimensioned.
Sets the extension of a witness line beyond the tick mark. When you set this value,
this is the size at which the witness line plots, if you are printing at 100 percent.
You can select any of the annotations symbols loaded in the project. The centerline
symbol appears above the witness lines that reference the centerlines of family in-
stances and walls. If the witness line does not reference a center plane, you cannot
place a centerline symbol above it.
Changes the line pattern of the witness lines of the dimension, if the dimension
references are the centerlines of family instances and walls. If the references are not
at the centerline, this parameter does not affect the witness line pattern.
Changes the tick mark at the ends of the centerline of a dimension.
Designates the tick mark display for inner witness lines when adjacent segments of
a dimension line are too small for arrows to fit. When this occurs, the ends of the
short-segment string flip, and the inner witness lines display the designated interior
tick mark. This parameter is only enabled when the tick mark type parameter is set
to an arrow type. See Changing the Dimension Line Tick Mark
Line Weights. See Line Weights
Changing the Dimension Line Tick
on page 287.
Dimension Properties | 291
Project
on page
