Adding or Removing Segments from a Wall Reveal

You can continue an existing reveal onto new walls, or remove segments from a reveal.
1 Open a view that displays the reveal, and select the reveal.
2 Click Modify Reveals tab
3 Select the walls to continue adding to or removing from the reveal.
4 To exit the Add/Remove Walls tool, press Esc twice.

Changing the Wall Reveal Profile

1 Select a wall reveal in a 3D or elevation view, or click Home tab
drop-down
2 Click Modify Reveals tab (or Place Reveal tab)
drop-down
3 For Profile, select the desired profile type.
4 Click OK twice.

Moving Wall Reveals Away from or Towards the Wall

After placing a wall reveal, you can move its ends away from or toward the wall. The procedure is the same
as moving wall sweeps back to the wall. See

Changing the Wall Reveal Type

1 In the drawing area, select a wall reveal.
2 Click Modify Reveals tab
Selector drop-down.
If the desired wall reveal type is not listed in the Type Selector, you can load additional profile families. Click
Insert tab Load from Library panel

Wall Reveal Properties

You can modify several properties for wall reveals, including profiles and offsets.
Modifying Wall Reveal Properties
1 In a 3D or elevation view, select a wall reveal and click Modify Reveals tab
panel Element Properties.
2 In the Instance Properties dialog, edit wall reveal instance parameters.
3 Click Edit Type to edit wall reveal type parameters.
Changes made to type properties affect all wall reveals of this type in the project. You can click
Duplicate to create a new wall reveal type.
4 When you are finished, click OK.
Reveal panel
Reveal.
Type Properties.
Returning Wall Sweeps Back to the Wall
Element panel, and select the desired wall reveal from the Type
Load Family.
Add/Remove Walls.
Build panel
Element panel Element Properties
Wall
on page 665.
Element
Wall Reveals | 671
