2 Select and move the end drag control near the bubble to resize the level line.
3 Click the Add Elbow drag control (
As you drag a control, the cursor snaps at points similar to the neighboring level lines. The cursor also snaps
as the segments form straight lines.

Level Properties

Parameter names, values, and descriptions for levels. Most values are modifiable.

Modifying Level Properties

1 In a project view, select a level line, and click Modify Levels tab
2 In the Instance Properties dialog, edit instance properties.
3 To edit type properties, click Edit Type.
4 Click OK.

Level Type Properties

Name
Constraints
Elevation Base
Graphics
Line Weight
1104 | Chapter 18 Annotating and Detailing
the bubble away from the level line.
Bubble dragged from level line
When you move the bubble end out of line, the effect appears only in that view, no other views
are affected. The segments created from dragging the bubble have a solid line style. You cannot
change this style.
Properties.
Changes made to type properties affect all level lines of that type in the project. You can click
Duplicate to create a new level line type.
Description
If the elevation base value is set to Project, the elevation reported on a level is with
respect to the project origin. If the base value is set to Shared, then the elevation
reported is with respect to the shared origin. To change the shared origin, you can
relocate the project. See
Sets the line weight for the level type. You can change the definition of the line
weight number using the Line Weights tool. See
), then drag the control to the desired location to move
Relocating and Mirroring a Project
Line Weights
Element panel Element
on page 1300.
on page 495.
