Detaching Columns

1 In the drawing area, select the column you want to detach. You can select multiple columns.
2 Click Modify Columns tab
3 Click the target you want to detach the column from.

Coarse-Scale Cut Patterns

If you join a wall and a column, and the wall has a coarse-scale fill pattern defined, the joined column
assumes that pattern. See
and section views. The section view plane must cut through the joined face of the 2 elements.
Wall and column joined (column assumes the fill pattern of the wall)
NOTE Structural columns do not assume the walls fill pattern, even when joined.
If the column is attached to the target by its top and bottom, click Detach All on the Options
Bar to detach the top and bottom of the column from the target.
Curtain Wall Properties
Modify Column panel
on page 786. This behavior is evident in coarse-scale plan
Detach.
Detaching Columns | 763
