Align with Element. Patterns align with the host and compute a good origin.
For information on applying these patterns, see
Custom Fill Pattern

Creating a Custom Fill Pattern

1 Click Manage tab
2 In the Fill Patterns dialog, under Pattern Type, select Drafting or Model.
3 Click New.
4 If you are creating a drafting fill pattern, select how to orient the fill pattern in the host layers.
5 In the New Pattern dialog, select Custom.
6 Click Import.
7 Select the desired pattern file (PAT), and click Open. See
8 Click the menu next to Import to view the list of available patterns. Select a pattern from the
9 If desired, enter a new name for Name.
10 If desired, enter a value for Import scale.
11 Click OK twice.
462 | Chapter 10 Customizing Project Settings
on page 462.
Project Settings panel
See Fill Pattern Host Orientation
information on creating a custom pattern (PAT) file.
NOTE Default Revit Architecture fill patterns are stored in the revit.pat and revit metric.pat files in the
Revit Architecture program group Data directory. The revit metric.pat file contains various metric
masonry and iso patterns.
list.
Creating a Simple Fill Pattern
Settings drop-down
on page 461 for details.
Custom Pattern Files
on page 460 or Creating a
Fill Patterns.
on page 466 for
