Conceptual Design Model Line Instance Properties

You can modify many line properties for a conceptual design massing family. Lines have instance properties
because they are not yet part of a family. When a line is selected, click Modify Lines tab
panel Instance Properties to access the Model Lines Instance Properties dialog. (See
on page 808.)
Name
Constraints
Work Plane
Graphics
Visible
Visibility/Graphics Overrides
Dimensions
Length
Identity Data
Subcategory
Is Reference Line
Other
Reference
Model or Symbolic
Related topics
Drawing on a Planar Surface
Creating Solid Forms
Creating Void Forms
Description
The work plane to which the line is related.
Turns visibility on or off, and accesses the
Associate Family Parameter dialog for
viewing existing parameters and adding
new ones.
Sets the 3D views for the View Specific
Display and sets the Detail Levels to
Coarse, Medium, or Fine.
The actual line length.
Sets the line subcategory to Form [projec-
tion] or Void.
Changes the unconstrained reference line
to a reference line. Displays the Associate
Family Parameter dialog that lists existing
parameters and adds new parameters.
Sets the reference type to Not a Reference,
Weak Reference, or Strong Reference.
The actual type of line.
on page 534
on page 552
on page 553
Conceptual Design Model Line Instance Properties | 535
Element
Model Line Properties
