2 Add the schedule or area scheme to a sheet.
3 Select the schedule or area scheme on the sheet, and click Modify Schedule Graphics
4 Open the main project.
5 If the Revit model (from which you want to include project parameters or area schemes) is
6 In the main model, open a sheet view.
7 Click Modify tab
8 If you unloaded the linked Revit model, you need to reload it.
The project parameters or area schemes should now be available to schedule.
Including Room Information in a Door Schedule
You can include information in a door schedule about the room a door leads to and the room a door leads
from. Typically, the door swing indicates the room the door is leading to or from. For example, in the
following image door 56 leads from the hall to the bedroom.
178 | Chapter 5 Project Views
tab Clipboard panel
already linked in the main project, unload the linked model.
To unload the linked Revit model:
a Click Manage tab
b In the Manage Links dialog, click the Revit tab.
c Select the linked model, and click Unload.
d Click Yes to confirm, and click OK to exit the Manage Links dialog.
Clipboard panel
To reload the linked Revit model:
a Click Manage tab
b In the Manage Links dialog, click the Revit tab.
c Select the linked model, and click Reload.
d Click OK to exit the Manage Links dialog.
Copy.
Manage Project panel
Paste.
Manage Projects panel
Manage Links.
Manage Links.
