Overriding Graphic Display of Element Categories

NOTE If you need to override the visibility or graphic display for an individual element, see
and Graphic Display of Individual Elements
1 Open the view in which you want to override the graphic display of element categories.
2 Right-click an element in the drawing area, and click Override Graphics in View
3 If necessary, click the appropriate tab in the Visibility/Graphics dialog (Model Categories,
4 Highlight a category row.
5 Click the Override button for the line or pattern to edit.
6 For lines, edit the line weight, line color, and line pattern. For patterns, edit the fill color and
7 (Optional) Select the Halftone check box next to a category to blend the line color of an element
8 For model categories, you can also select a detail level at which to display the element category.
9 Click Apply to view your changes, and click OK to exit the Visibility/Graphics dialog.
Related topics
Controlling Visibility and Graphic Display of Elements Using Filters
Removing Graphic Display Overrides for Element Categories
Applying Transparency to Faces of Model Element Categories
When you use this method, the element s category is already highlighted when the
Visibility/Graphics dialog opens.
Alternatively, you can click View tab
shortcut VG or VV.
NOTE If you open the Visibility/Graphics dialog from a drafting view, only those categories that can
appear in a drafting view display.
Annotation Categories, or Imported Categories).
If you are overriding element categories in a linked Revit model
a Click the Revit Links tab.
b Click the button in the Display Settings column.
c In the RVT Link Display Settings dialog, click Custom.
d Click the appropriate tab (Model Categories, Annotation Categories, or Imported Categories).
e Select Custom from the drop-down menu.
NOTE For annotation and imported categories, you can only override projection and surface display.
fill pattern.
with the background color of the view. This produces a lighter shade for the line color. (See
Halftone/Underlay on page 497.)
The detail level of the category overrides the detail level of the view. For example, you can set
a wall to display at medium or fine detail level to see its structure, even if the view detail level
is set to coarse.
You cannot set the detail level for subcategories. They inherit it from their parent category.
on page 199.
Graphics panel
on page 202
on page 203
Overriding Graphic Display of Element Categories | 201
Overriding Visibility
Visibility/Graphics, or use the keyboard
on page 204
By Category.
