Foundation slabs may be used to model structural floors on a grade, which do not require support from
other structural elements. Foundation slabs may also be used to model complex foundation shapes that
cannot be created using Isolated or Wall Foundation tools.

Adding Foundation Slabs

1 Click Home tab
2 Click Create Floor Boundary tab
3 In the Instance Properties dialog for type, specify the structural floor type, and click OK.
4 Click Create Floor Boundary tab
5 Click Extend into wall on the Options Bar if you want the offset to be measured from the wall's
6 Specify an offset for slab edges in the Offset text box on the Options Bar.
7 Click Create Floor Boundary tab
8 Click the foundation, and select the desired Foundation family type on the Family drop-down
Related topics
Cutting Openings in Structural Floors
Modifying Structural Floors
Structural Floor
Structure panel
to select the walls in your model.
core.
NOTE Instead of picking walls you can sketch a foundation slab. Use the sketch tools on the Create
Floor Boundary tab Draw panel to form the boundary of the foundation slab. The sketch must
form a closed loop or boundary condition. See
list.
NOTE Foundation slabs are added below the level in which they are drawn. Therefore, if you add a
foundation slab in Level 1, it is added below Level 1 and will not be visible in the Level 1 plan view.
To see the foundation slab in a plan view, create a new level below Level 1, for example, Foundation
Level. When you create a new level below Level 1, you will also be able to see the foundation slab as
an underlay (displayed in halftone) in Level 1.
Foundation slab below foundation level
on page 937
on page 929
Foundation drop-down
Element panel Floor Properties.
Draw panel Boundary Line and then click
Sketching
Floor panel Finish Floor.
on page 934
Foundation Slab.
on page 303.
Adding Foundation Slabs | 941
(Pick Walls)
