To adjust the distance between the current point of view and the pivot point you use the Drag Distance
indicator. The Drag Distance indicator has two marks on it that show the start and destination distances
from the current point of view. The current traveled distance is shown by the orange position indicator.
Slide the indicator forward or backwards to decrease or increase the distance towards the pivot point.
To reorient a view by moving towards or away from the model
1 Display the big Tour Building wheel.
2 Click and hold down the Forward wedge.
The Drag Distance indicator is displayed.
NOTE If you click the Forward wedge once, the model moves forward 50% of the distance between the
current location and the pivot point.
3 Drag the cursor up or down to change the distance from which you view the model.
4 Release the button on your pointing device to return to the wheel.
Look Tool
With the Look tool, you can rotate the current view vertically and horizontally. When rotating the view,
your line of sight rotates about the current eye position, like turning your head. The Look tool can be
compared to you standing in a fixed location, and looking up or down while turning your head left or right.
When using the Look tool, you adjust the view of the model by dragging the cursor. As you drag, the cursor
changes to the Look cursor and the model rotates around the location of the current view.
In addition to using the Look tool to look around a model, you can also use the tool to pan the current view
to a specific face on the model. Press and hold the SHIFT key before selecting the Look tool on one of the
Full Navigation wheels.
Walking through a Model
When using the Look tool from the big Full Navigation wheel, you can walk through a model by using the
arrow keys on the keyboard. Use the Options dialog for the SteeringWheels to adjust the walk speed.
