Split curtain wall panels
Curtain Wall as Wall Panel
A curtain wall type can be applied to a wall panel, which has the effect of nesting a curtain wall within a
curtain wall.
Curtain wall with curtain wall panel

Modifying Curtain Walls

You can modify the appearance of curtain walls through their properties. Curtain wall properties are modifiable
before or after you draw the walls.
To specify curtain wall properties, you can access instance properties or type properties.
Select the wall, and click Modify Walls tab
Properties or Type Properties.
Click Home tab Build panel
click Element Properties drop-down
See Element Properties on page 120.
Changing Curtain Wall Panel Type
You can change the panel type applied to a curtain wall by selecting an individual panel and then selecting
a different type from the Type Selector. If there are not enough wall types loaded, load more families using
the Load Family tool. For more information, see
Element panel
Wall, select a curtain wall type from the Type Selector drop-down, and
Instance Properties or Type Properties.
Loading Families
Curtain Walls, Curtain Grids, and Mullions | 781
Element Properties drop-down
on page 427.
Instance
